(LLX08309)

Warranty: This product includes a 12-month warranty covering defects in materials and workmanship under normal use.

The warranty excludes damage caused by incorrect installation, misuse, accidents, or exposure to conditions beyond the rated environmental specifications (e.g. voltage, moisture, or vibration levels).

Claims must be made within the warranty period and accompanied by proof of purchase. For all warranty enquiries or to lodge a claim, please contact our team via our Contact page.

• 1300 effective lumens flood beam output
• Thermal plastic housing prevents LED overheating
• Sealed to IP67 and IP69K for harsh environments
• EMC-compliant to CISPR25 Class 3
• Lightweight body (220g) with polycarbonate lens
• 4 x 3W high-efficiency LEDs
• Single-bolt mounting with DT04-2P connector

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.

• Part No: LLX08309
• Voltage Range: 10–30V DC (12V/24V compatible)
• Light Output: 1300 effective lumens
• Power: 12W (4 x 3W LEDs)
• Current Draw: 0.9A @ 13V
• Beam Pattern: Flood
• Shape: Round
• Lens: Polycarbonate
• Mounting: Single bolt
• Connector: DT04-2P
• IP Rating: IP67 / IP69K
• EMC Rating: CISPR25 Class 3
• Vibration Resistance: 20G
• Size (HxWxD): 97 x 71 x 49 mm
• Weight: 0.22 kg
• Warranty: 1 Year

SKU	LLX08309
Barcode #	9324310375230
Brand	OEX
Shipping Weight	0.3000kg
Shipping Width	0.100m
Shipping Height	0.150m
Shipping Length	0.100m
Shipping Cubic	0.001500000m3
